The Cub Cadet® Ultima Series ZT1 46 46-in. 21.5 HP Zero-Turn Lawn Mower with AeroForce™ Fabricated Deck is designed to deliver a premium cut with few clumps and stragglers, fine clippings and evenness. Dual hydrostatic transmissions engineered for quick ground speeds that leaves your yard with a professional-quality finish. A continuous tubular steel frame with fully e-coated corrosion defense system designed to help protect against wear and tear.

Specifications

• Model Number: 17AIEACNA10
• Series: Ultima Series™ ZT
• Hour Meter: Available separately
• Mulch Kit: Available separately
• Headlight(s): Dual LED
• Cup Holder: Yes
• Operator Presence System: Yes

Engine

• Engine Brand: Kawasaki®
• Engine Model: FR Series
• Engine Model Number: 651V
• Engine Displacement: 726cc
• Engine Output: 21.5HP
• Starter Type: Electric
• Fuel Tank Capacity: 3.5 gal. US (13.25 L)
• Cylinders: Twin
• Engine Start: Ignition Key
• Engine Oil Capacity: 2.0 qts. US (1.89 L)
• Lubrication: Fully pressurized
• Charging System: 12 amp regulated
• Fuel Gauge: No
• Governor: Mechanical
• Choke: Separate Choke
• Air Filter: Dual element
• Oil Filter: Yes
• Fuel Delivery: Carburetor

Cutting Deck

• Deck Cutting Width: 46 in
• Deck Wash: No
• Deck Material: 11-gauge steel
• Deck Engagement (PTO): Electric
• Deck Construction: Fabricated
• Blade(s): 2
• Deck Lift: Foot pedal with Dial Adjust
• Cutting Height Range: 1" - 4.5"
• Anti-Scalping: 2 gauge wheels
• Deck Positions: 15

Drive System

• Transmission: Hydro-Gear EZT 2200
• Forward Speed: 7 MPH / 11.3 km/h
• Reverse Speed: 3.5 MPH / 5.6 km/h
• Drive System: Hydrostatic

Chassis

• Frame: 2" x 2" tubular steel
• Turning Radius: 0°
• ROPS: No
• Rear Tow Hitch: Yes
• Corrosion Protection: Yes

Controls

• Cruise Control: No
• Brakes: Disc
• Steering Control: Lap Bars
• Parking Brake: Lap Bar Integrated

Comfort

• Seat Type: 20" High-back
• Armrests: No
• Seat Adjustment: Knob
• Front Caster Suspension: No

Wheels

• Rear Tires: 20"x8"-8"
• Front Tires: 11"x6"-5"
• Tire Tread: Turf Master / Multi Trac

Battery

• Battery: 210 CCA
• Battery Type: AGM (Absorbent Glass Mat)
• Battery Voltage: 12V

Warranty

• Warranty: 3-year unlimited hours
• Frame Warranty: Lifetime limited
• Deck Shell Warranty: Lifetime limited
• Commercial Warranty: No
